Compuprint 4247-X03 Multi-Form Printers at a glance
Max. Print Speed Model 4247-X03 cps (at 10 cpi):
Data processing mode 800
DP text mode 400
NLQ mode 200
Print options
13.6"/345.44 mm maximum print line Vertical spacing: 6 or 8 lpi selectable from operator panel for text 3, 4, 6, 8 or 9 lpi selectable under program control for text 1/144" increments under program control available for graphics Horizontal spacing: 10, 12, 15, 16.7, 17.1 and 20 cpi Proportional spacing is available in DP text and NLQ mode Bar codes: Postnet, UPC-A, UPC-E, EAN-13, Code 3 of 9, Code 128, Interleaved 2 of 5, Codabar, MSI and Matrix 2 of 5
Emulations
Standard: Epson FX, IBM Proprinter III XL and IBM 2381 Personal Printer and native 4247 mode Optional: Ethernet IPDS: IBM 4224, IBM 4230 and native 4247 mode
Paper handling
Support for two continuous forms paths Dual front tractors Paper parking, switching and linking Automatic forms loading and thickness adjustment
Paper Sizes
Continuous forms: 3" to 17" (76 mm to 432 mm) width, 3" to 24" (76 mm to 610 mm) length
Interfaces
Centronics Parallel, Serial (RS-232C), USB 2.0, Ethernet 10/100 BaseT
Physical characteristics 4247-X03:
26.4" x 17.7" x 12.6" (670 mm x 450 mm x 320 mm) (WxDxH), 46.3 lb./21 kg (weight)
