Printek Paper Drive Belt

The Printek Paper Drive Belt is a repair part for the PrintMaster Dot Matrix Printer models 860, 862, 850, 850si and 852si.

To Install the Paper Drive Belt:

1. Unplug the power cord.
2. Remove the right side cover.
3. Loosen the belt tensioner locking screw.
4. Push the tensioner pulley assembly toward the bottom rear of the printer and retighten the screw.
5. Remove the belt from the top pulley and then the motor pulley.
6. Install the new belt. Make sure that the belt teeth are engaged with the teeth on both pulleys and that the back side of the belt is against the tensioner pulley.
7. Adjust the belt tension.
8. Reinstall the right side cover.

×

×

×

×

×

×
