PrintMaster 702 Specifications:
Print Modes 700/702
Fast Draft 680 cps
HS-Draft 500 cps
Draft 333 cps
Letter Quality 111 cps
Graphics* up to 360 x 360
Character Matrix
Fast Draft: 24x8/80H
Draft: 24x12/120H
NLQ: 24x18
LQ: 24x36/360H
Printhead
24 pin (2 x 12; staggered), oval needle orientation
Printhead Adjustment
Gap adjustment is manual
Character Sets
HS Draft, Draft, Courier, Roman, Sans Serif, Prestige, Script,
OCR-A/B
Character Spacing
5, 6, 7.5, 8.6, 10, 12, 15, 17.1, 20 cpi
Line Length
80 columns at 10 cpi, /1/72" /1/180" /1/360 inches
Line Spacing
2, 3, 4, 6, 8, 12 lpi
Paper Handling
Zero-Tear, Paper Load/Paper out sensing,
Park Position, Manual/Single Cut Sheet
Fanfold continuous multi-layer forms
Optional 2nd Tractor
Continuous Mode
(PLM) Paper Load Mode - enable sets a horizontal carriage
movement in order to flatten the paper to the Upper friction
assembly
Operator Controls
Online Mode: Tear Advance
Offline Mode: Park, Form Feed/Line, Adjust for Tear position,
Top of Form and Head Gap
Form Parameters
Nonvolatile memory for eight forms, each designate: Paper
Path, cpi, lpi, form length, lft/Rt Margin, Skip perf, Ignore
Form Feed, Emulations, font
Operating Indicators
2 x 16 LCD for form selection; on/off line status, and error
descriptions
Ribbon
Cartridge: Nylon fabric, Mobius loop,
9 million char
Power Requirements
Auto-switching Voltage: 100 - 250 VAC
Frequency: 50 to 60 Hz
40 Watt printing: <10 Watt Power Save
Paper Slew Rate
5 ips
Paper Width
3.0" to 11" (76 to 278 mm)
Paper Loading
Friction (Single) and Tractor (FF-front/FF-rear/FF-pull)
Multi-Part Forms
Front 1+5 copies, Cut Sheet 1+5 copies
0.025" max. thickness
Graphics Density
up to 360 x 360
Horizontal: 60/70/80/90/120/180/240/360 DPI
Vertical: 90/180/360 DPI
Audible Noise (Draft Mode)
52 dBA
Setup (Automatic Methods)
Control Panel or Config File obtained from Web Page Config
Utility through USB connection
I/O Buffer
256k
Standard Interfaces
Parallel Bi-Directional, Ethernet 10/100 Mbit
USB 2.0 Full Speep, USB A Host (servicing)
Optional Interface: Serial RS232
Software Controls
Epson LQ-2550, Epson LQ-2180, Epson FX, IBM Proprinter
xI24e, IBM Proprinter xI24e+AGM, MTPL, 14 Industrial Barcodes,
or Basic Postnet and Intelligent Mail Barcodes
Physical Specifications
18.0 x 10.4 x 7.9 in (W x D x H)
Weight: 8,6kg, 18.9lbs
Reliability
MTBF - 15,000 hours @ 25% duty cycle
Printhead Life: 500 million dots per wire
Warranty: One-year printer warranty (Mfr)
